Typ 2413

Test institute without
1st Layer Standard
Special version and test without
Cleaning Without special instructions
Salt test without
Diaphragm material EPDM
For valve size DN 15 to 100/NPS ½ to 4
Diaphragm rupture indicator Without
Version according to TV-SK Without
9004 Document Without
RAL color Standard
Actuator Area 160 cm²
Hardning test without
Free of paint adhesion INHI Not required
Actuator version Diaphragm actuator
Suitable for valve Type 2412 or Type 2417
Painting acc. to Orga instruction R12/S
Cross-Cut-Test without
Mandrel bending test without
Coating system Standard
Special version varnish without
Layer thickness test without
Dust shield ACVA with or without DUSH
Inspection certificate paint Without
4th Layer Not present
2nd Layer Not present
Holiday-Test without
Dust test without
Pull-Off Test without
Surface finish Standard
Surface preparation Standard R12/S
Actuator housing material 1.0332
Pressure set point range 0.8 to 2.5 bar
Total layer thickness Standard
Leakage line connection Without
3rd Layer Not present
